Fixture parts
Plates, locating blocks, nests, brackets, pins, clamps, holders, and inspection fixture components
Key Service Details
Send drawings, material, quantity, tolerances, surface finish, and delivery requirements. XHR will review manufacturability before quotation.
Critical features
Hole position, flatness, parallelism, datum surfaces, and repeat assembly fit
Materials
Aluminum for lightweight fixtures, steel for wear areas, stainless steel for corrosion resistance
Production support
Prototype fixtures, replacement parts, and repeat small batches
Manufacturing Notes for Buyers
Why Fixture Parts Need Careful Review
Automation fixtures control position and repeatability. Small drawing or tolerance issues can create assembly drift, inspection error, or unstable machine operation.
Inspection Focus
XHR can focus inspection on datums, locating holes, pins, pockets, and mating faces so fixture parts match the intended assembly function.
Typical Applications
- Assembly fixture plates
- Inspection fixture components
- Locating nests and blocks
- Replacement automation tooling parts
Factory and Parts Gallery
Selected workshop and part images from XHR's website media library. More project photos can be added as case studies grow.
RFQ Checklist
- 2D drawing and 3D model when available
- Material grade, substitute options, and required certificates
- Prototype quantity, batch quantity, and expected repeat orders
- Critical tolerances, threads, datums, and inspection requirements
- Surface finish, cosmetic faces, packing, and delivery destination
Related CNC Machining Pages
FAQ
Can XHR machine one replacement fixture part?
Yes. Single replacement parts can be discussed when drawings or samples are available.
What should be included in fixture drawings?
Mark datums, locating holes, critical faces, tolerances, material, finish, and any assembly notes.
Can XHR support repeat fixture orders?
Yes. Repeat small batches can be supported when drawing revision and requirements remain clear.
Request a Quote for CNC Machining for Automation Fixtures and Jigs
Send drawings and requirements to XHR. We will review process, material, tolerance, finishing, delivery, and packing needs.
